📡 Ubiquiti UniFi nanoHD — Technical Information

📝 Overview

• Wi-Fi 5 (802.11ac Wave 2)compact indoor access point with technology.

• With MU-MIMO (multi-user, multiple-input multiple-output) support,multiple devices at the same timea high-speed connection.

• Small-sized design → aesthetic appearance, suitable for indoor space use.

• Central management with UniFi Controller software or UniFi Network application.

⚙️ Wireless Features

• Standart:IEEE 802.11 a/b/g/n/ac Wave 2

• Hız:

  • 2.4 GHz → 300 Mbps

  • 5 GHz → 1733 Mbps

  • Toplam:~2.03 Gbps

• MU-MIMO:4×4 (5 GHz) + 2×2 (2.4 GHz)

• Antenna Gain:

  • 2.4 GHz: 2.8 dBi

  • 5 GHz: 3 dBi

• Max. User:200+ simultaneous clients

🔌 Hardware & Power

• Ethernet Port:1 × 10/100/1000 Mbps RJ45

• PoE:802.3af PoE (15.4W)

• Max. Power Consumption:10.5 W

🔒 Security

• WPA-PSK, WPA-Enterprise (802.1X)

• VLAN support

• Guest Network

• Hotspot support (portal, coupon, speed limit)

📐 Physical Properties

• Boyut:Ø 160 × 32.65 mm

• Ağırlık:300 g

• Montaj:Ceiling / wall mounting device included

• Renk:White (optional different colored covers available)

🌐 Management & Software

• UniFi Network Controller / Mobile App support

• Multi-site management

• RF optimization, automatic channel selection

• Traffic analysis, user statistics

• Zero-Handoff Roaming

🚀 Usage Scenario

• Offices, cafes, hotels, schoolsHigh-performance wireless access in dense client indoor environments.

• Institutions that require centralized management with UniFi infrastructure.

• Use in decorative areas (lobby, restaurant, store) due to its small size.
