U6-LR, Wi-Fi 6 (802.11ax)a technology that supports and offers long rangeaccess point'tir. Long range ve high performanceThis model is ideal for installations that require effective wireless network distribution, especially in large areas.
Wi-Fi Standard:
802.11a/b/g/n/ac/ax (Wi-Fi 6)
Frequency Band:
2.4 GHz ve 5 GHz (dual-band)
Maximum Wireless Speed:
2.4 GHz600 Mbps (2x2 MU-MIMO)
5 GHz2400 Mbps (4x4 MU-MIMO & OFDMA)
Toplam: 3000 Mbps (3 Gbps)
Antenna Gain:
2.4 GHz5.4 dBi
5 GHz6.5 dBi
Channel Width:
20, 40, 80 MHz @ 2.4 GHz
20, 40, 80, 160 MHz @ 5 GHz
MU-MIMO and OFDMAIt enables more devices to connect simultaneously with support.
Ethernet Port:
1 x 10/100/1000 Mbps RJ45Power over Ethernet In
PoE Support:
802.3af PoE (48V)works with
PoE adapter in the boxyoktur)
Maximum Power Consumption:13W
Boyutlar:220 x 220 x 45 mm
Ağırlık:500 g (cihaz) 700 g(with assembly set)
MontajSuitable for ceiling and wall mounting.
Assembly kits are included in the box.
IP Protection:Sadece Indoor useis suitable for
Operating Temperature-30°C to +70°C Humidity: 5% – 95% non-condensing
Management Platform:
UniFi Network ControllerCloud-based management support
Management with the UniFi mobile application
Supported Features:
VLAN support
Guest Network & Captive Portal
Zero Handoff Roaming
Band steering, Quality of Service (QoS), Traffic Shaping
Support for DFS (Dynamic Frequency Selection) channels
RF analysis, management interface capable of analysis
UniFi 6 LR (U6-LR) AP
Ceiling and wall mounting apparatus
Screws and installation guide
⚠️ PoE adapter is not included.
Large offices and commercial spaces
Schools, hospitalssuch intensive usage areas
Large meeting rooms, event areas
Retail stores ve kafeler
