Mikrotik RB922UAGS-5HPacD-NM

  • Stok Kodu: Belirtilmedi.
  • Kategori: NetMetal,Basebox AP
  • Marka: Mikrotik
SORUNUZ
%3 İndirim
KDV Dahil 572.14 TL
Piyasa Fiyatı 595.49 TL
  • Ürün Özellikleri
  • Taksit Seçenekleri
  • Kargo ve Garanti
  • Ürün Yorumları
  • Ürün Videosu

Product specifications

Details
Product code RB922UAGS-5HPacD-NM
SFP DDMI yes
CPU nominal frequency 720 MHz
CPU core count 1
Size of RAM 128 MB
10/100/1000 Ethernet ports 1
MiniPCI-e slots 1
Wireless standards 802.11a/n/ac
Wireless chip model QCA9882
Number of USB ports 1
802.3af support no
Supported input voltage 8 V - 30 V
PoE in Yes
Voltage Monitor Yes
PCB temperature monitor Yes
Dimensions 143x247x48mm (PCB)
Operating System RouterOS
License level 4
CPU QCA9557
Max Power consumption 19W
SFP ports 1
USB slot type USB type A
Number of chains 2
Storage type NAND
Storage size 128 MB


Wireless specifications

5 GHz
  Transmit power (dBm) Receive Sensitivity Transmit power (mW)
6MBit/s 31 -96 1259
54MBit/s 27 -81 501
MCS0 30 -96 1000
MCS7 27 -77 501
MCS9 22 -72 158

wireless parameters may be limited in software, depending on your local regulatory limitations

Included parts

K-25 screw kit

Gigabit PoE injector

DIN mount (K-27)

Metal ring (one)

24V 1.2A power adapter

Plastic zip tie

Ethernet test results

RB922UAGS-5HPacD-NM QCA9557 1G all port test
Mode Configuration 1518 byte 512 byte 64 byte
kpps Mbps kpps Mbps kpps Mbps
Bridging none (fast path) 81.2 986.1 234.9 962.2 477.7 244.6
Bridging 25 bridge filter rules 81.2 986.1 118.4 485.0 119.5 61.2
Routing none (fast path) 81.2 986.1 234.9 962.2 408.2 209.0
Routing 25 simple queues 81.2 986.1 158.3 648.4 165.8 84.9
Routing 25 ip filter rules 64.8 786.9 70.4 288.4 60.9 31.2
  1. All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
  2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
  3. Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
  4. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
