RBMetalG-52SHPacn

The MikroTik RBMetalG-52SHPacn is a durable, fully waterproof wireless access point designed for outdoor use with high output power. It offers high-speed wireless connections with 802.11ac support and a Gigabit Ethernet port.​

📦 Hardware Specifications

• Model: RBMetalG-52SHPacn

• İşlemci: Qualcomm Atheros QCA9556, 720 MHz

• RAM: 64 MB

• Depolama: 16 MB Flash

• Ethernet Port: 1 x 10/100/1000 Mbps Gigabit Ethernet

• Wireless Chip: QCA9889

• Wireless Standards: 802.11a/n/ac (5 GHz), 802.11b/g/n (2.4 GHz)

• Antenna Connector: N-male

• Power Input: 10–30 V DC (Passive PoE supported)

• Maximum Power Consumption11 W

• Operating Temperature: -40°C to +70°C

• Boyutlar: 215 x 60 x 38 mm

• Ağırlık: Device: 300 g; Package: 778 g

• Operating System: RouterOS, License Level 4

📡 Wireless Features

• Operating Frequencies:

  • International Version:

    • 2.4 GHz: 2412–2484 MHz

    • 5 GHz: 5150–5875 MHz

  • US Version (RBMetalG-52SHPacn-US):

    • 2.4 GHz: 2412–2462 MHz

    • 5 GHz: 5170–5250 MHz, 5725–5835 MHz

• Channel Width: Maximum 80 MHz

• MIMO Support: Single chain (1x1)

• Antenna Gain:

  • 2.4 GHz: 6 dBi

  • 5 GHz: 8 dBi

• Data Rate:

  • 2.4 GHz: up to 300 Mbps

  • 5 GHz: Up to 433 Mbps

📦 Box Contents

• RBMetalG-52SHPacn device

• 24V 0.8A power adapter

• Gigabit PoE injector

• Dual band 2.4/5 GHz omni antenna (6 dBi / 8 dBi)

• 2 metal mounting rings

• Angled N connector​

🎯 Areas of Use

• Outdoor wireless access point

• Wireless backbone connections

• Customer premises equipment (CPE) applications

• Long-distance point-to-point or point-to-multipoint connections​
