MIMOSA C5C WITHOUT ADAPTER

Mimosa C5C, It is a high-performance and modular radio unit designed for long-distance point-to-point (PtP) and point-to-multipoint (PtMP) wireless connections. This model, sold without an adapter, stands out with its flexible antenna options and robust technical features.

📡 Basic Technical Specifications

• Maximum Data Rate: 700 Mbps IP (866 Mbps PHY)

• Frequency Range: 4.9 – 6.4 GHz (may vary by country)

• Modülasyon: 2x2:2 MIMO OFDM, 256-QAM

• Channel Width: 20/40/80 MHz (adjustable in 5 MHz increments)

• Output Power: 27 dBm

• Receiver Sensitivity (MCS 0):

  • -87 dBm @ 80 MHz

  • -90 dBm @ 40 MHz

  • -93 dBm @ 20 MHz

• Gecikme: <1 ms (in TDMA mode)

• Operating Modes: PTP Backhaul, PTMP Client

🔌 Power and Connection

• Power Consumption: Maximum 12.9 W

• Power Supply: Passive PoE (24–56 VDC)

• Ethernet Port: 1 x 10/100/1000 Mbps RJ-45

• Antenna Connection: 2 x RP-SMA (female)

🛠️ Physical Properties

• Boyutlar: 188.4 x 65 x 44 mm

• Ağırlık: 295 grams

• Montaj: Single clamp for direct mounting

• Operating Temperature: -40°C to +55°C

• Moisture Resistance: 5% – 100% (condensing)

• IP Protection ClassIP55

🌐 Software and Management

• Management Interface: HTML5-based web interface, HTTPS

• Remote Management: Mimosa Cloud, SNMPv2, Syslog

• QoS and VLAN Support: 4 predefined QoS levels, VLAN tagging (Q-in-Q, triple tagging)

• Spectrum Management: Channel optimization with active scanning

📦 Package Contents and Compatible Accessories

The Mimosa C5C, sold without an adapter, does not include a power adapter and antenna. Therefore, you also need to obtain the following accessories:

• Power AdapterPassive PoE supported 48–56 VDC power supply (for example, Mimosa PoE-24V Gigabit PoE adapter)

• AntenDual-polarized, RP-SMA connector antennas (for example, Mimosa N5-X series)
