MIMOSA C5-POE+EU

Mimosa C5-POE+EU is a compact Gigabit PoE (Power over Ethernet) wall adapter designed for Mimosa C5 and C5c radio devices, compatible with European-style sockets. This adapter provides a clean and organized setup by using a single Ethernet cable to supply power to devices and for data transmission.

🔌 Technical Specifications

• Input Voltage: 100–240V AC, 50–60 Hz

• Output Voltage: 56V DC, 0.275A

• Power Output: 15.4W

• Connection Type: 2 x RJ-45 Gigabit Ethernet port

• Pinout:

  • Pin 1/2 and 4/5: Data (LAN)

  • Pin 3/6: +56V DC

• LED Indicator: Power indicator

• Plug Type: Type C (European standard)

• Boyutlar: 51 mm (Height) x 86 mm (Width) x 33 mm (Depth)

• Ağırlık: 0.11 kg

• Operating Temperature: -40°C to +55°C

• Protection Class: UL60950-1, IEC 60950-1, EN 55022, RoHS

✅ Compatible Devices

Mimosa C5-POE+EU is compatible with the following Mimosa devices:

• Mimosa C5

• Mimosa C5c

• Mimosa C5x

• Mimosa A5c

• Mimosa A6

🛠️ Advantages

• Compact Design: Thanks to its compact structure that can be directly plugged into a wall outlet, it eliminates cable clutter and provides a professional installation.

• High Security: It provides lightning protection compliant with IEC 61000-4-5 standards.

• Wide Compatibility: It is compatible with devices such as Mimosa's C5, C5c, C5x, A5c, and A6.

📦 Package Contents

• 1 x Mimosa C5-POE+EU Gigabit PoE Wall Adapter

• 1 x European Type C5 Power Cable
