RBLHGG-60ad

MikroTik RBLHGG-60ad(at the market usuallyLHG 60Gis known as), is a high-speed outdoor CPE (Customer Premises Equipment) device that uses 60 GHz wireless connection technology. It is specifically designed to eliminate interference issues and provide high bandwidth in environments where the 2.4 GHz and 5 GHz bands are congested.

🔧 Technical Specifications

• Model Code: RBLHGG-60ad

• İşlemci: IPQ-4019, quad-core ARM Cortex A7, 716 MHz

• Mimari: ARM 32-bit

• RAM: 256 MB

• Depolama: 16 MB Flash

• Kablosuz: Integrated 60 GHz 802.11ad (QCA6335 chipset)

• Ethernet: 1 piece 10/100/1000 Mbps Gigabit Ethernet port

• RouterOS License Level: Level 3

• Operating System: RouterOS

• IPsec Hardware Acceleration: Desteklenir

• Boyutlar: Ø 391 x 222 mm

• Operating Temperature: Between -40°C and +70°C

• Protection Class: IP55

• MTBF (Mean Time Between Failures): Approximately 200,000 hours @ 25°C

⚡ Power and Energy Consumption

• Input Voltage: 12–57 V DC (802.3af/at and passive PoE supported)

• Power Input: 1 piece PoE-IN

• Maximum Power Consumption:5 W

• Soğutma: Pasif

📡 Wireless Performance and Range

• Wireless Standard: 60 GHz 802.11ad

• Maximum Data Rate: Up to 2 Gbps

• Point-to-Point (PtP) Range: Up to 1500 meters

• Point-to-Multipoint (PtMP) Range: Up to 800 meters

• Antenna Gain: 42 dBi

• Beam Width: 3°

📦 Box Contents

• LHG 60G device

• 24V 0.38A power adapter

• Gigabit PoE injector

• LHG assembly fixture

• Aim tool for precise alignment

💡 Highlighted Features

• High Speed Connection: It provides data transmission speeds of up to 2 Gbps thanks to the 60 GHz frequency band.

• Parasite Blocking: The 60 GHz band is less crowded compared to the 2.4 GHz and 5 GHz bands, thus minimizing interference issues.

• Durable Design: The IP55 certified outer casing provides protection against harsh weather conditions.

• Easy Installation: Thanks to the assembly tool and Aim tool included in the box, it offers precise alignment and easy setup.

LHG 60G is an ideal solution to meet high-speed and reliable connection needs, especially in areas with dense wireless network traffic. It is suitable for both point-to-point and point-to-multipoint connections and works compatibly with 60 GHz access points such as MikroTik's wAP60G AP or wAP 60Gx3 AP.
