RB912UAG-2HPnD

MikroTik RB912UAG-2HPnD is a compact and high-performance wireless router device. It offers flexible expansion options with an integrated 2.4 GHz high-power wireless card and an additional miniPCIe slot. With its Gigabit Ethernet port, it can utilize the full potential of 802.11n wireless speeds.​

🔧 Technical Specifications

• Product Code: RB912UAG-2HPnD

• İşlemci: Atheros AR9342, 600 MHz, 1 core

• RAM: 64 MB DDR2

• Depolama: 128 MB NAND Flash

• Operating System: RouterOS, License Level 4

• Boyutlar: 105 x 105 mm

• MTBF: Approximately 100,000 hours (at an ambient temperature of 25°C)

• Operating Temperature: -40°C to +70°C

📡 Wireless Features

• Frequency Band: 2.4 GHz (2400–2500 MHz)

• Standartlar: 802.11b/g/n (Wi-Fi 4)

• Maximum Data Rate: 300 Mbps

• MIMO: 2x2 MIMO, dual chain

• Antenna Connections: 2 x MMCX

• Wireless Chip: AR9342

• Output Power: 30 dBm at MCS0, 24 dBm at MCS7

• Purchase Sensitivity: MCS0 at -96 dBm, MCS7 at -78 dBm​

🔌 Connection and Expansion

• Ethernet: 1 x Gigabit Ethernet (10/100/1000 Mbps)

• USB: 1 x USB 2.0 Type-A (maximum 1A current)

• miniPCIe Slot: 1 unit (for 802.11 wireless card, 3G/4G modem or LoRa module)

• SIM Slot: 1 x Mini SIM (for 3G/4G modem use)​

⚡ Power and Other Features

• Power Input: 8–30 V DC (via DC jack or passive PoE)

• Maximum Power Consumption: 13.5 W

• Soğutma: Pasif

• Koruma: 16kV ESD protection on Ethernet and MMCX ports

• Hardware Specifications: PCB temperature and voltage monitoring, beeper​

📦 Package Contents

• RB912UAG-2HPnD device

• Power adapter

• PoE injector

• Assembly accessories​

🌐 Areas of Use

• Wireless Access Point (AP): It is ideal for providing wireless access in small and medium-scale networks.

• Customer Premises Equipment (CPE): It is available for end-user connections for internet service providers.

• Scalable Network Solutions: The miniPCIe slot allows for network capacity expansion with an LTE modem or additional wireless cards.​
