🔧 Basic Features

• Product Code: E60iUGS

• Architecture & CPU:ARM architecture,EN7562CTprocessor, 2 cores, ~950 MHz

• RAM:512 MB DDR3

• Depolama:128 MB NAND

• Operating System / License:RouterOS v7 — License level 4

🌐 Network & Port Structure

• Ethernet Ports:5 units of Gigabit RJ-45

• SFP Port:1 piece,2.5 Gb/s destekli

• USB:1 × USB-A (USB 3.0) type

• PoE Features:
  • PoE-in (802.3af/at) via Port #1
  • Passive PoE-out via Port #5, voltage dependent on applied voltage but output current limit ~0.5 A

⚡ Power & Consumption

• Power Inputs:2 (DC jack and PoE-in)

• DC Jack Input Voltage:12-57 V

• PoE-in Voltage:18-57 V

• Maximum Power Consumption:~23 W (~5 W when accessory is not connected)

📐 Physical & Other Properties

• Boyutlar:113 × 89 × 28 mm

• Operating temperature:-40 °C → +70 °C

• Soğutma: Pasif

• Status Monitoring:CPU temperature, PCB temperature, voltage monitor

💼 Performance & Usage Notes

• Switch Chip Model:EN7562CT — Integrated with CPU

• IPsec hardware acceleration: Var

• Esneklik:Freedom to configure ports as WAN, LAN, or bridge
