ATLGM&EG18-EA

The MikroTik ATLGM&EG18-EA is an LTE base station solution that stands out with its high-speed LTE connectivity and durable outdoor design. This device is ideal for providing high-performance internet access, especially in challenging environmental conditions.​

📦 Hardware Specifications

• Product Code: ATLGM&EG18-EA

• İşlemci: Marvell 88F3720, dual-core, 1.2 GHz ARM 64-bit

• RAM: 256 MB DDR3L

• Depolama: 16 MB Flash

• Operating System: RouterOS v7 (License Level 3)

• Boyutlar: 391 x 391 x 227 mm

• Operating Temperature: -40°C to +70°C

• MTBF: Approximately 200,000 hours @ 25°C

• Antenna Structure: 4x4 MIMO, high-gain directional antennas​

📡 LTE and Mobile Network Features

• LTE Category: 18

• Download Speed: 1.2 Gbps

• Loading Speed: 150 Mbps

• LTE Band Support:

  • FDD: 1 (2100 MHz), 3 (1800 MHz), 5 (850 MHz), 7 (2600 MHz), 8 (900 MHz), 20 (800 MHz), 28 (700 MHz)

  • TDD: 38 (2600 MHz), 40 (2300 MHz), 41 (2500 MHz)

• 3G Band Support:

  • 1 (2100 MHz), 3 (1800 MHz), 5 (850 MHz), 8 (900 MHz)

• LTE Modem: R11mL-EG18-EA

• SIM Slot: 1 piece Micro SIM

• MiniPCIe Slot: 1 piece​

🔌 Connection and Power

• Ethernet Port: 1 unit Gigabit Ethernet (10/100/1000 Mbps)

• PoE Input: 802.3af/at supported

• Input Voltage: 12–57 V

• Maximum Power Consumption: 8 W

• Soğutma: Passive (fanless)
