ML2.5-60-BF-18-EU

📡 General Description

ML2.5-60-BF-18-EU, A high-performance one produced by Cambium Networks2.5 GHz frequency bandIt is a directional microwave antenna designed for. This antenna is particularly suitable for fixed wireless access and long-distance PTP (Point-to-Point) connections.

⚙️ Technical Specifications

• Model: ML2.5-60-BF-18-EU

• Frequency Band:2.5 GHz (within the range of 2.4 GHz - 2.7 GHz)

• Kazanç:18 dBi

• Polarizasyon:Dual polarization

• Half Power Beam Width:Approximately 60° (Wide-angle beam)

• VSWR:≤ 1.5

• Empedans:50 Ohm

• Connection Type:TwistPort or N-female connector (depending on model variation)

• Malzeme:Durable aluminum alloy, coating resistant to outdoor conditions.

🔌 Physical Properties

• Boyut:Compact, portable structure

• Ağırlık:Approximately 1-2 kg

• Montaj:Compatible with pole or wall mounting accessories.

• Dayanıklılık:Weather-resistant, UV-protected

🌡️ Working Conditions

• Operating Temperature:-40°C to +70°C

• Nem:5% - 95% (non-condensing)

• Koruma:IP65 or higher water and dust protection

📍 Areas of Use

• Fixed wireless access points

• Long and medium distance PTP connections

• Telecommunications infrastructures

• Urban and rural wireless network installations

✅ Advantages

• Easy alignment with wide-angle beam

• Suitable for harsh environmental conditions due to its durable structure.

• Performance increase with dual polarization support

• Compact and lightweight design
