| Özellik | Değer |
|---|---|
| Frequency Range | 4.9 – 6.4 GHz (broadband 5 GHz support) |
| Gain | 30 dBi |
| Beam Angle (Beamwidth): | |
| - Horizontal | ~6° |
| - Vertical | ~6° |
| Polarizasyon | Dual-Polarized (2x2 MIMO – H + V) |
| VSWR | < 1.5:1 (typical) |
| F/B Ratio (Front-to-Back) | >30 dB |
Connection Type:2 x N-Female connector
Uyumluluk:
IgniteNet MetroLinq 5
Beam5 AC
Other standard 2x2 MIMO 5GHz devices
| Özellik | Değer |
|---|---|
| Diameter (Dish Diameter) | Approximately 65–70 cm |
| Montaj | With direct mounting apparatus (azimuth/tilt adjustment supported) |
| Wind Resistance | 160–200 km/h |
| Koruma | External environment resistance at IP65 level |
| Color / Material | Gray / UV resistant aluminum or plastic reflector |
Point to point (PtP)long-distance connections
(Line of sight up to >10–30 km)
WISPSpine connections
Backhaul(main carrier connection) applications
Camera systems or high-speed wireless bridges between campuses.
High gain (30 dBi)with maximum signal quality and minimum loss
Narrow beam angle with high resistance to interference.
Fully compatible with IgniteNet devices, integrated mounting capability.
