| 📌 Feature | 📊 Details |
|---|---|
📶 Number of Ports | 16 × GPON ports |
📡 Optical Module Types | Compatible with B+, C+, C++ SFP modules |
🌐 Data Rate | Downstream (Tx): ~ 2.488 Gbit/s Upstream (Rx): ~ 1.244 Gbit/s |
📏 Broadcast / Distance | Maximum fiber distance ~ 20 km (with single-mode fiber) |
🔆 Optical Power & Sensitivity (for C++ module) | Output power: 6 … 10 dBm Receiver sensitivity: ≤ –35 dBm |
🔄 Split Ratio (Division) | In B+ modules: 1:64 In C+ / C++ modules: 1:128 |
⚡ Power Consumption | Static: ~ 26 W Maximum load: ~ 50 W |
🧮 MAC Address Capacity | It supports 32,768 MAC addresses. |
📦 Maximum Frame Size | Normal: ~ 2.004 bytes If jumbo frame mode is active: It can support up to 9,216 bytes. |
🌡 Operating Temperature / Environment | –25 °C … +65 °C |
| 📐 Dimensions (WxDxH) | ~ 22.86 mm × 237.00 mm × 395.40 mm |
In high-capacity infrastructures,support from a large number of subscribers sağlar
C++ with moduleshigher optical output powerand the possibility of longer distance access
Since the split ratio can go up to 1:128, efficient use of fiber resources
Compatible with Huawei OLT systems, modular design facilitates easy system integration.
With jumbo frame support, it is possible to carry large packets (if enabled).
