EXTRALINK PATCHCORD LC/APC-MULTIMODE DUPLEX OM2 3.0MM 5M

📌 Product Name:

Extralink LC/APC – LC/APC Multimode Duplex Patchcord OM2, 3.0mm, 5m

🔧 Technical Specifications:

🔹 Fiber Type:

• Multimode (OM2)

• Core/Cladding:50/125 µm

• Kategori:OM2 (according to ISO/IEC 11801 standard)

• Renk:Orange (the standard color of OM2)

🔹 Connection Terminals:

• Connector Type:LC/APC (at both ends)

  • LC: Small form factor connector

  • APC: Angled Physical Contact (8° angled end, provides low reflection)

• Yapı: Duplex(bidirectional – TX/RX)

🔹 Cable Structure:

• Cable Diameter:3.0 mm (common outer sheath for both vessels)

• Case Material:LSZH (Low Smoke Zero Halogen) – low smoke, halogen-free

• Cable Type:Duplex zipcord

🔹 Uzunluk:

• 5 meters

🔹 Light Source Compatibility:

• Genellikle LED or VCSELused with base optical transmitters (in the range of 850 nm – 1300 nm)

🔹 Input/Output Loss:

• Insertion Loss:< 0.3 dB (typical)

• Reflection (Return Loss):> 55 dB (High performance thanks to APC)

💡 Areas of Use:

• Data centers

• Connection of multimode optical network devices

• Patch panel – connections between switch or media converter

• LAN / SAN infrastructures

⚠️ Note:

• OM2 multimode fiber, 850 nmIt performs best at the wavelength of light and generallyUp to 300 metersIt is suitable for 1 Gbps connections.

• LC/APC connector, although typically associated with singlemode, it can also be preferred in some special multimode applications (should be carefully selected with compatible devices).
