Areas of Use:
10 BASE-T (Ethernet), 100 BASE-T (Fast Ethernet), 100 VG-AnyLAN, 4/16 Mbps Token Ring, 100 Mbps CDDI, 52/155 Mbps ATM
İletken:Electrolytic mono copper conductor
İzolatör:Solid polyethylene
Büküm:Twisted in pairs, all pairs are twisted together.
Ayırıcı:Polyester tape was used.Outer Sheath:Polyethylene (PE) resistant to UV (ultraviolet) rays, black color
| Conductor Resistance / km | 94 Ω |
| Insulation Resistance (500 V DC) | 5,000 MΩ |
| Effective Capacity (nF / km) | 56 nF/km |
| Resistance Imbalance | %2 |
| Propagation Speed | 67% – 69% |
| Operating Voltage | 250 V |
| Test Voltage | 1,200 V (test voltage) |
| Characteristic Impedance | 100 Ω ±15% (in the 1–100 MHz range) |
Bending Radius (Minimum):8 × D (cable outer diameter)
Operating Temperature Range:–55 °C to +60 °C
