ePMP 5 GHz Force 300-19 SM ROW/EU (C050900C806A)

📡 General Description

ePMP Force 300-19 SM, Cambium’sePMP 3000 seriesCompatible with,It is a high-performance subscriber module (Subscriber Module - SM).. 19 dBi integrated panel antennahas and802.11ac Wave2based architecture withhigh speed, low latency, and advanced MIMO support sunar.

⚙️ Basic Technical Specifications

• Model Name:Force 300-19 SM

• Part Number: C050900C806A

• Frequency Range:

  • 4910 – 5970 MHz (ROW)

• Channel Width:20 / 40 / 80 MHz

• Maximum PHY Rate:700+ Mbps

• MIMO:2x2 MIMO (MU-MIMO support on the AP side)

• Modülasyon:QPSK – 256 QAM

• TDD Synchronization:Cambium GPS Sync supported

📶 Antenna Features

• Antenna Type:Integrated panel antenna

• Antenna Gain: 19 dBi

• Coverage Angle:

  • Horizontal: 15°

  • Vertical: 15°

• Polarizasyon:Dual Slant (±45°)

🔌 Power and Connection

• Ethernet Port:

  • 1 × 10/100/1000 Mbps Gigabit Ethernet (RJ45)

• PoE Power Input:

  • 30 VDC passive PoE

  • Power Consumption: ~10 W

• PoE Adapter: Kutuya dahildir

🧱 Physical Properties

• Boyutlar:26.7 × 12.4 × 4.3 cm

• Ağırlık:~800 g

• Protection Class: IP55

• Operating Temperature:-30°C to +60°C

• Wind Resistance:200 km/h

• Montaj:

  • Direct mounting kit included

  • Adjustable ±15° tilt setting

🌐 Software & Management

• Arayüzler:

  • Web GUI

  • CLI (SSH)

  • cnMaestrosupport (cloud/local)

• Routing Modes:Bridge, NAT/Router

• QoS:3 levels (data, voice, video)

• Güvenlik:

  • WPA2 AES

  • Radius authentication

  • MAC filtering

📦 Box Contents

• 1 × Force 300-19 SM device

• 1 × Mounting apparatus

• 1 × 30V PoE adapter + power cable

• Installation guide

📍 Areas of Use

• Long-distance subscriber connections for WISPs

• Video surveillance systems

• Corporate connections requiring high-speed data transmission

• ePMP 3000 APs for PtMP applications
