A powerful one developed for medium and large-scale networksCloud Router Switch modelidir.
This model, unlike the classic CRS series, has built-inWi-Fi 6 (4x4 MIMO, dual-band)also provides support.
8x PoE output gigabit port enables direct power supply to devices.
Total of 17x Gigabit Ethernet ports
10G fiber connection capability via 2x SFP+ slot
Internal 4x4 MIMO Wi-Fi 6 access point
RouterOS v7 and flexible management options with L3 HW Offloading support
⚙️ Hardware & Performance
CPU: Quad-Core ARM IPQ-8072A, 2.2 GHz
CPU Architecture: ARM 64-bit
RAM: 1 GB DDR3
Storage: 128 MB NAND
Switch Chip: 98DX226S
Operating System: RouterOS v7 (L5)
🔌 Ports & Connections
17 × Gigabit Ethernet (8 × PoE-out)
2 × 10G SFP+ uplink
1 × Gigabit Management port (directly connected to the CPU)
1 × USB 3.0 (Type-A)
Internal Wi-Fi 6 (4x4 MIMO)
2.4 GHz: 802.11b/g/n/ax – 5 dBi antenna
5 GHz: 802.11a/n/ac/ax – 6 dBi antenna
⚡ PoE Features
PoE-out over 8 ports (802.3af/at & 24V Passive PoE)
Total PoE power: 150 W
Max. output current (at input below 30 V): 1.1 A / port
Max. output current (at input above 30 V): 0.56 A / port
🔋 Power & Cooling
Dual AC power input (100–240 V, redundant)
Power consumption: 43 W (idle) / 227 W (maximum)
Active fan cooling system
📐 Physical Properties
Dimensions: 44 × 250 × 443 mm
Dimensions (with antenna): 210 × 250 × 443 mm
Operating temperature: –20 °C ~ +70 °C
🛠️ Software & Management
RouterOS v7 (L2/L3 switching & routing)
L3 HW Offloading support
VLAN, ACL, QoS, CAPsMAN
Advanced monitoring & traffic shaping
SNMP support
