Frequency Range:4.8 – 6.1 GHz
Kazanç:27 dBi – provides high directivity with dual polarization support.
3 dB Beamwidth:5° typical – minimizes interference with a narrow beam.
VSWR:Approximately 1.4:1 – good impedance match
Empedans:50 Ω
Max. Input Power:25 W
Konnektörler:2 × N‑Female (dual pol.)
Side Lobe & Back Lobe:Compliant with ETSI EN 302.326‑3 standards, front‑to‑back ≈ 40 dB
Polarization Isolation:≈ 25 dB max, 32 dB typical; port-to-port isolation ≈ 32 dB max, 45 dB typical
Çap:550 mm
Weight (including bracket):3.4 kg
Wind Capacity:Operation: 140 km/h; Survival: 200 km/h
Operating Temperature:–50 °C … +70 °C
Montaj:Included 25–60 mm pole-compatible pan/tilt bracket
Point-to-Point Connections:Ideal for distances over 10 km.
Operating in Parasitic Environments:It maintains signal quality with high gain and narrow beamwidth.
Supported by MIMO Systems:Data capacity and connection stability are increased with dual polarization.
ANT-HP5527N offers a powerful solution for long-range, high-performance wireless links with high gain (27 dBi), narrow beam width, and robust mechanical features. Its reliable operation even in challenging environmental conditions makes it a preferred model for operators and professional network installations.
If you need assistance with other model suggestions or system integration matters, I would be happy to help!
