60 GHz cnWave V3000 Client Node Radio Only (C600500C024A)

📡 General Description

cnWave V3000, Using Cambium's 60 GHz millimeter wave technology,high capacity, low latency ve offering fiber-like speedsIt is a client device. Specifically,In metropolitan areas, FTTX (fiber to the x)in alternative solutions andin applications requiring high bandwidth kullanılır.

⚙️ Basic Technical Specifications

• Model Name:V3000 Client Node

• Part Code (SKU): C600500D001A

• Frequency Band:57 – 71 GHz (60 GHz band, may vary by country)

• Max. Channel Width:2.16 GHz

• Data Transfer Capacity (PHY):

  • Up to 7.6 Gbpstotal capacity

  • Full-duplex at gigabit speeds

• MIMO:2x2 MIMO

• Modülasyon:QPSK – 64-QAM (automatic)

• Protokol:TDMA / TDD

• Platform:Based on IEEE 802.11ay

📶 Antenna Features

• Antenna Type:Directed, integrated

• Antenna Gain: 44.5 dBi

• Beamforming:Exists (automatic redirection & alignment)

• Connection Type:Point to Point (PtP) and Point to Multipoint (PtMP)

• Typical Connection Distance:

  • Between 500 and 1500 meters, with a clear line of sight

  • Up to 2+ km under ideal conditions

🔌 Connection & Power

• Ethernet Port:

  • 1 × 2.5 Gbps Ethernet (RJ45)

• Power Consumption:18 – 25 W

• Power Supply:

  • 802.3at (PoE+)

  • 56V AC PoE adapter (compatible with N000065L001C)

• PoE Injector:Usually sold separately.

🧱 Physical Properties

• Boyutlar:19.5 cm (diameter) x 10 cm (depth)

• Ağırlık:~1.5 kg

• Montaj:

  • Steerable bracket (compatible with Precision Mount C000000L125A)

• Protection Class:IP66/IP67 (dustproof and waterproof)

• Operating Temperature:-40°C to +60°C

• Wind Resistance:Up to 200 km/h

🌐 Management & Software

• Management Interface:

  • cnMaestro (cloud/on-premises)

  • Web GUI / CLI

• Güvenlik:

  • AES 128-bit data encryption

  • MAC filtering

  • VLAN support

• OTA (Update): Evet

🧰 Box Contents

• 1 × cnWave V3000 Client Node

• Mounting kit (for pole mounting)

• Power adapterprovided optionally

📌 Areas of Use

• Fiber alternative broadband connections

• Fixed wireless access (FWA) in urban areas

• Video surveillance and security systems

• Corporate network extension for schools, municipalities, public institutions

• 60 GHz PtP and PtMP deployments

📈 Featured Advantages

✅ Can reach speeds similar to fiber
✅ In confined spaces, the parasitic effect is low.
✅ Ease of automatic alignment with Beamforming
✅ Long distance access thanks to high antenna gain
