Ubiquiti UniFi Access Point U6 Long-Range (U6-LR)
Ubiquiti UniFi U6-LR WiFi 6 Long-Range Ceiling-Mounted Access Point
Overview:
The Ubiquiti UniFi U6-LR is a ceiling-mounted access point featuring WiFi 6 (802.11ax) technology with 8 spatial streams and extended signal range. Its dual-radio 2.4 GHz and 5 GHz architecture delivers data rates up to 2.4 Gbps and supports PoE+ (802.3at) for high-performance wireless coverage in enterprise networks.
Description:
The U6-LR is a ceiling-mounted WiFi 6 access point from Ubiquiti's UniFi family. With 8 spatial streams, it supports multi-user MIMO (MU-MIMO) and OFDMA technologies for efficient connectivity in dense environments. It operates on the 5 GHz band using the WiFi 6 (802.11ax) standard, while providing WiFi 4 (802.11n) compatibility on the 2.4 GHz band. It achieves data rates ranging from 7.3 Mbps to 2.4 Gbps. With 18.5W power consumption and a supported voltage range of 44–57V, it is powered via PoE+ (802.3at). The device is designed for wide-area coverage in enterprise networks and can be centrally managed with the UniFi network management software.
Key Highlights:
- WiFi 6 (802.11ax) technology with 8 spatial streams (5 GHz)
- Dual-radio 2.4 GHz and 5 GHz support
- High data rates up to 2.4 Gbps
- Optimized design for extended signal range
- Power and data over a single cable via PoE+ (802.3at)
- Ideal form factor for ceiling mounting
- Full integration with the UniFi network management system
Technical Specifications:
| Parameter | Value |
|---|---|
| Product Model | U6-LR |
| SKU | ST01233 |
| Wireless Standard | 802.11ax (WiFi 6) 5 GHz, 802.11n (WiFi 4) 2.4 GHz |
| Spatial Streams | 8 |
| Operating Frequencies | 2.4 GHz and 5 GHz |
| Data Rate Range | 7.3 Mbps – 2.4 Gbps |
| Power Consumption | 18.5W |
| Supported Voltage Range | 44–57V |
| Power Source | PoE+ (802.3at) |
| Mounting Type | Ceiling Mount |
| Management | UniFi Network Management Software |
