EXTRALINK PATCHCORDSM LC/APC-LC/APC DUP 9/125 3M
Extralink LC/APC-LC/APC SM Duplex 3M Fiber Patchcord
Overview:
Extralink OS2 LC/APC-LC/APC Duplex Singlemode 9/125 fiber patchcord is designed for long-distance, high-bandwidth fiber optic connections with LC/APC duplex connector construction and OS2 singlemode 9/125 µm fiber cable. It provides a standard singlemode patchcord form with a yellow jacket, 2.0 mm cable diameter, and 2 fiber strands.
Description:
Extralink LC/APC-LC/APC SM Duplex fiber patchcord is terminated with LC duplex 1.25 mm form factor ceramic ferrule connectors and APC (Angled Physical Contact) polishing on both ends. The OS2 9/125 µm singlemode fiber has a 9 µm core and 125 µm cladding and supports 10 Gigabit speed from 5-10 km at 1310 nm and 30-40 km at 1550 nm. Corning optical fiber core supports low-loss, high-bandwidth fiber optic performance. Maximum connector loss is 0.50 dB, typical connector loss is 0.30 dB, and typical return loss is -55 dB. The cable features a yellow 2.0 mm jacket, 2 fiber strands, OFNR UL rating, and ROHS compliance for riser, backbone, and fiber-only applications. It is fully inspected and tested in accordance with ANSI/TIA/EIA-455-171-A-2001 attenuation standards. Operating temperature is -20°C to +70°C; storage temperature is -40°C to +70°C.
Key Highlights:
- LC/APC - LC/APC duplex termination
- OS2 9/125 µm singlemode fiber
- 10 Gigabit speed from 5-10 km at 1310 nm and 30-40 km at 1550 nm
- Maximum 0.50 dB connector loss, typical 0.30 dB connector loss
- Typical -55 dB return loss
- 2.0 mm yellow jacket and 2 fiber strands
- OFNR UL rating and ROHS compliance
- Tested in accordance with ANSI/TIA/EIA-455-171-A-2001
- Lifetime warranty
Technical Specifications:
| Parameter | Value |
|---|---|
| Product Type | Singlemode 9/125 µm Fiber Optic Patch Cable / OS2 Fiber Jumper Cord |
| Termination | LC to LC Fiber Optic Cable |
| Connector 1 | LC Duplex, 1.25 mm form factor connector, ceramic ferrule |
| Polish Connector 1 | APC (Angled Physical Contact) |
| Connector 2 | LC Duplex, 1.25 mm form factor connector, ceramic ferrule |
| Polish Connector 2 | APC (Angled Physical Contact) |
| Max Connector Loss | 0.50 dB |
| Typical Connector Loss | 0.30 dB |
| Typical Return Loss | -55 dB |
| Optical Mode Type | OS2 (9/125 Singlemode) - 9 µm core, 125 µm cladding; 10 Gigabit speed from 5-10 km at 1310 nm and 30-40 km at 1550 nm |
| Core / Cladding | 9/125 µm - 9 µm core diameter, 125 µm cladding diameter |
| Core Material | Corning Optical Fiber |
| Mode Type | Singlemode – 9/125 Singlemode OS2 Fiber Cable; high speed and high bandwidth over long distances |
| Strand Count | 2 Fiber Strands |
| Jacket Color | Yellow |
| Jacket OD | 2.0 mm |
| UL Rating | OFNR (Optical fiber, nonconductive, riser) - certified for riser, backbone, fiber-only applications and vertical runs |
| Compliance | ROHS Compliant |
| Quality Control | Fully inspected and tested in accordance with ANSI/TIA/EIA-455-171-A-2001 attenuation standards by a qualified fiber optic technician |
| Warranty | Lifetime |
| Storage Temperature | -40°C to +70°C |
| Operating Temperature | -20°C to +70°C |
| UPC | 670628010431 |
