ANT-HP5529N

Technical Specifications

Frequency Range:

4800 - 6100 MHz

Gain:

29 dBi

3dB Beamwidth:

4.0 degrees

Sidelobes:

ETSI EN 302.326-3 DN1-DN5

Polarization:

Vertical and Horizontal

Fron to Back Ratio:

-40 dB

Cross polarization

-28 dB (max), -32 (typ)

Port-to-Port Isolation

-32 dB (max), -45 (typ)

VSWR:

1.4:1(typ)

Wind Load(Survival):

190 km/h

Size:

660mm x 660mm x 450 mm

Weight: (Mounting Included)

6.1 Kg

Connector:

2 x N-male

Operating Temperature:

-50C to 70C

Material:

Aluminum, ABS

Additional Features:

Broadband dual polarizedAntenna

Mounting Kit:

Included/Pole Mount
